![Heli-Coil - Single Insert, #8-32 UNC, 3D, Stainless Steel Screw Locking Insert - 13-1/4 Free Coils, 0.492 Inch Overall Length, 0.205 to 0.22 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0006284-23_1024x1024.jpg?v=1586838422)
Heli-Coil - Single Insert, #8-32 UNC, 3D, Stainless Steel Screw Locking Insert - 13-1/4 Free Coils, 0.492 Inch Overall Length, 0.205 to 0.22 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00062844
Brand: Heli-Coil
Model #: A3585-2CN492
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #8-32 |
Overall Insert Length (Decimal Inch) | 0.4920 |
Tang | Tangless |
Length to Diameter Ratio | 3D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2050 |
Maximum Outside Diameter (Decimal Inch) | 0.2200 |
Finish/Coating | Bright |
Number of Free Coils | 13-1/4 |
Maximum Locking Torque (In/Lb) | 9 |
Minimum Break Away Torque (In/Lb) | 1.50 |
Thread Standard | UNC |
Material Grade | 304 |
