Heli-Coil - Single Insert, #8-32 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 6 Free Coils, 0.246 Inch Overall Length, 0.205 to 0.22 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00062810
Brand: Heli-Coil
Model #: A3585-2CN246
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #8-32 |
| Overall Insert Length (Decimal Inch) | 0.2460 |
| Tang | Tanged |
| Length to Diameter Ratio | 1-1/2D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.2050 |
| Maximum Outside Diameter (Decimal Inch) | 0.2200 |
| Finish/Coating | Bright |
| Number of Free Coils | 6 |
| Maximum Locking Torque (In/Lb) | 9 |
| Minimum Break Away Torque (In/Lb) | 1.50 |
| Thread Standard | UNC |
| Material Grade | 304 |
