Heli-Coil - Single Insert, #6-40 UNF, 2D, Stainless Steel Screw Locking Insert - 8-3/8 Free Coils, 0.276 Inch Overall Length, 0.173 to 0.193 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00062778
Brand: Heli-Coil
Model #: A3591-06CN276
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #6-40 |
Overall Insert Length (Decimal Inch) | 0.2760 |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1730 |
Maximum Outside Diameter (Decimal Inch) | 0.1930 |
Finish/Coating | Bright |
Number of Free Coils | 8-3/8 |
Maximum Locking Torque (In/Lb) | 6 |
Mininum Break Away Torque (oz-in) | 1.00 |
Thread Standard | UNF |
Material Grade | 304 |
