![Heli-Coil - Single Insert, #2-56 UNC, 2D, Stainless Steel Screw Locking Insert - 7-3/8 Free Coils, 0.172 Inch Overall Length, 0.11 to 0.119 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0006242-23_1024x1024.jpg?v=1586838287)
Heli-Coil - Single Insert, #2-56 UNC, 2D, Stainless Steel Screw Locking Insert - 7-3/8 Free Coils, 0.172 Inch Overall Length, 0.11 to 0.119 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00062422
Brand: Heli-Coil
Model #: A3585-02CN172
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #2-56 |
Overall Insert Length (Decimal Inch) | 0.1720 |
Tang | Yes |
Tang | Tanged |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1100 |
Maximum Outside Diameter (Decimal Inch) | 0.1190 |
Finish/Coating | Bright |
Number of Free Coils | 7-3/8 |
Maximum Locking Torque (oz-in) | 20 |
Mininum Break Away Torque (oz-in) | 3.00 |
Thread Standard | UNC |
Material Grade | 304 |
