Emuge - 1-3/8 - 12 UNF H5 6-Flute NE2 Finish Cobalt Straight Flute Machine Tap
Item #: 96373402
Brand: Emuge
Model #: CU803011.5055
Features and Benefits
Modified bottoming is similar to bottoming, but the chamfer is longer and has more teeth. They are used for threading blind holes and have 2 to 2-1/2 threads.
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
| Product Specifications | |
|---|---|
| Tap Type | Machine Tap |
| Thread Size (Inch) | 1-3/8 - 12 |
| Class of Fit | 3BX |
| Thread Limit | H5 |
| Number of Flutes | 6 |
| Chamfer | Modified Bottoming |
| Material | Cobalt |
| Finish/Coating | NE2 |
| Thread Direction | Right Hand |
| Through Coolant | NonThrough Coolant |
| Thread Standard | UNF |
| Overall Length (Decimal Inch) | 6.69291 |
| Overall Length (mm) | 170.00 |
| Oversize | No |
| Series/List | CU803011 |
| Thread Length (Decimal Inch) | 4.1250 |
| Tapping Depth (mm) | 52 |
| Shank Diameter (Decimal Inch) | 1.1080 |
| Square Size (Decimal Inch) | 0.8310 |
| Material Application | Stainless Steel |
| Material Application2 | Steel |
